Example of Suzuki VZ800 Marauder 1997 1998 1999 2000 2001 2002 Workshop Service Repair Manual CONTENT: The DOWNLOAD LINK is on BOTTOM of the PAGE. Example: PARAGRAPH from Suzuki VZ800 Marauder 1997 1998 1999 2000 2001 2002 Workshop Service Repair Manual. PERIODIC MAINTENANCE for Suzuki VZ800 Marauder.
BRAKE for Suzuki VZ800 Marauder. Inspect Initially at 1 OOO km (600 miles, 1 months) and Every 6 000 km (4 000 miles, 6 months) thereafter. FRONT BRAKE for Suzuki VZ800 Marauder. Brake fluid level for Suzuki VZ800 Marauder. • Keep the motorcycle upright and place the handlebars straight. • Check the brake fluid level by observing the lower limit lines on the front brake fluid reservoir.
• When the level is below the lower limit line, replenish with brake fluid that meets the following specification. Specification and Classification: DOT 4. WARNING: The brake system of this motorcycle is filled with a glycol-based brake fluid.
Instant Download: 1997 - 2003 Suzuki Marauder VZ800 Service Shop Workshop Repair Manual + BONUS Parts Manual VZ 800 - service and repair. Suzuki Intruder VZ800 Pdf User Manuals. View online or download Suzuki Intruder VZ800 Manual.
Do not use or mix different types of fluid such as silicone-based or petroleum- based. Do not use any brake fluid taken from old, used or unsealed containers.
Never re-use brake fluid left over from the last servicing or stored for a long period. WARNING: Brake fluid, if it leaks, will interfere with safe running and immediately discolor painted surfaces. Check the brake hoses and hose joints for cracks and oil leakage before riding. • Remove the brake caliper. The extent of brake pad wear can be checked by observing the grooved limit 1 on the pad. 2017 Honda Atv Service Manual on this page. When the wear exceeds the grooved limit, replace the pads with new ones.
(Refer to page 6-12). CAUTION: Replace the brake pad as a set, otherwise braking performance will be adversely affected. DRIVE CHAIN for Suzuki VZ800 Marauder. ADJUSTING • Loosen or tighten both chain adjusters 2 until the chain has 1 5 — 25 mm (0.6— 1.0 in) of slack in the middle between engine and rear sprockets. The marks 3 on both chain adjusters must be at the same position on the scale to ensure that the front and rear wheels are correctly aligned.
• Place the motorcycle on its side-stand for accurate adjustment. • After adjusting the drive chain, tighten the axle nut securely. • Tighten both chain adjuster lock nuts 4 securely. Rear axle nut: 65 N-m (6.5 kg-m, 47.0 Ib-ft). HERE YOU CAN DOWNLOAD Suzuki VZ800 Marauder 1997 1998 1999 2000 2001 2002 Workshop Service Repair Manual.
